Curved Knife Die

Curved Knife Die (commonly referred to in industrial manufacturing as a curved die, press brake curved die, or sometimes translated as "curved upper die," "curved knife," or "bending knife die") is a highly practical upper die for CNC press brakes used in the metal processing and sheet metal bending industries.

Inquiry

Details
Inquiry
Related Products

Core Functions and Advantages of the Curved Knife Die：
Excellent Anti-Interference Ability (Clearance): When a workpiece needs secondary or multiple bending operations (for example, making a box with four high sides, a deep U-shaped groove, or products with return flanges/dead edges), a standard straight blade punch will directly hit the already bent vertical edges. The bent blade/gooseneck die, with its recessed 'curved' shape, can perfectly avoid these obstacles.

Material	42CrMo, HSS, tungsten steel etc	Size	Various size available, support customization

Application	Press Brake/Bending machine	Shaping Mode	Extrusion Mould

Hardness	45-60HRC	Surface Finishing	Bright Poolish

OEM	YES	Surface treatment	Heat treatment

Design software	CAD	Brand	Aclpress

Q: Which brands of press brakes is this bending die compatible with?
A: It works with domestic and international standard/non-standard press brakes like Yangli, Yawei, Jinfangyuan, Nantong, Xuzhou, Amada, etc. Just provide the machine model, and we can match it.

Q: How thick of a sheet can it bend?
A: It can bend common sheets from 0.3mm to 50mm, including cold-rolled steel, stainless steel, aluminum, galvanized sheet, copper, and more.

Q: Does it support custom non-standard options?
A: Yes! Customization is available: special angles, special R radius, special lengths, special V grooves, step dies, louver dies, forming dies, and more.

Q: Is it in stock? Is shipping fast?
A: Standard dies are largely in stock, with same-day or next-day shipping. Packed in wooden crates and delivered via nationwide logistics.
