Adjustable Offset Die
In the fields of metalworking and bending, an Adjustable Offset Die is commonly referred to as an 'adjustable joggeling die,' 'adjustable Z-bending die,' or 'adjustable offset tool.' It is a highly efficient, specialized tooling used on press brakes to form a 'Z-shape' (offset/joggle) bend in sheet metal in a single stroke.
- Details
- Inquiry
- Related Products
In traditional bending, creating a Z-shape (i.e., two consecutive right-angle bends in opposite directions with a transition in between) requires making the first bend, repositioning the workpiece, and then making the second bend. This process is not only time-consuming but also prone to dimensional inaccuracies due to positioning errors.
An Offset Die, on the other hand, features a mating 'stepped' design for both the punch (upper die) and the die (lower die). With just a single stroke of the press brake, it simultaneously performs two bends in opposite directions, directly forming a standard Z-shaped offset.
| Product Name | Adjustable Offset Die | Standard | DIN GB ISO JIS BA ANSI |
| Place of Origin | Anhui,China | Shipping Time | 14 Days |
| Color | Natural color | Forming way | Punching, Blanking, Bending, Burning, Deep drawing, Forming etc. |
| Hardness | HRC 58-62 | Product Certification | ISO 9001:2015 |
Q: Are you a factory or trading company?
A: We are a factory which has been producing metal stamping parts for more than 20 years.
Q: What are your main products?
A: We specialize in manufacturing metal stamping tool ,metal stamping parts.sheet metal parts,cnc machining part and welding structural parts etc.
Q: Can I get the samples?
A: Yes, sample order is available for quality check and market test, and it will be freight collect payment. If simple sample, we will not charge cost; If OEM/ODM samples, we will charge for the sample cost.
